Solenoid Valve Test Equipment (WH-FD08-801A)

The Solenoid Valve Test Equipment (Model WH-FD08-801A) is a precision station for gas solenoid and electromagnetic valves. It measures action voltage, response time, gas tightness, flow characteristic and durability with multi-channel acquisition, automatic threshold judgment and full data traceability — for incoming inspection at appliance plants and final QC at valve manufacturers. A valve that fails to open, closes too slowly or leaks gas is a safety-critical defect, so the WH-FD08 tests every valve consistently.

What the Equipment Tests

• Action voltage — pull-in and drop-out voltage thresholds.
• Response time — opening and closing time against the specification.
• Gas tightness — leak testing of valve seats and seals; see gas tightness testing.
• Flow characteristic — flow rate through the valve at rated pressure.
• Durability / endurance — repeated action cycles; see switch durability testing and fatigue testing machines explained.

Standards & Compliance

Valves are tested against the manufacturer’s specifications and the relevant IEC/EN/GB gas-appliance safety requirements, including IEC 60335-2-102 and the gas-tightness methods in gas tightness & flame failure testing. The equipment produces traceable records for supplier audits; see certifications.

How a Test Runs

1. Load the valve on the multi-channel fixture and connect gas/electrical lines.
2. Sweep voltage to find pull-in and drop-out thresholds.
3. Measure response time, tightness and flow characteristic.
4. Run endurance cycles where required, then export a pass/fail report.

Manual vs. Multi-Channel Automated Testing

Key Features

• Multi-channel action, tightness and flow testing.
• Response-time and action-voltage measurement.
• Automatic threshold judgment and traceability.
• Endurance cycle testing.
• Custom fixtures for high-mix valve types.

Applications

• Solenoid valve makers — production-line action and tightness verification.
• Gas appliance plants — incoming QC of solenoid valves before assembly.
• OEM / tier suppliers — custom fixtures and automated judgment for high-mix lines.

For complete appliance tightness testing, see the gas stove gas tightness test bench.

Why Manufacturers Choose Wanhe

Wanhe Testing (Zhongshan, Guangdong) builds appliance test equipment in-house with a 1-year warranty, lifetime technical support and OEM/ODM customization. Review compliance credentials on certifications & compliance, the factory-direct model on Factory Direct, and the buyer checklist in how to choose a manufacturer.

• Direct manufacturer — factory pricing with no trading margin; see factory direct vs trading.
• Traceable results — high-accuracy measurement with automatic pass/fail reports.
• Custom engineering — fixtures, stations and MES connection; see custom lead time.
• Export documentation — CE/ISO support and technical files.

Request a Configuration & Quotation

Send us your appliance models, target markets and the standards you must meet. Wanhe engineers will propose the station layout, confirm measurement ranges and quote lead time and MOQ. Use the contact form, or review typical budget ranges in the gas test equipment price guide.

Frequently Asked Questions

Which valve parameters are measured?

Action voltage, response time, gas tightness, flow characteristic and durability, each with automatic pass/fail judgment.

Can it test multiple valves at once?

Yes. The multi-channel fixture tests several valves in parallel for production throughput.

Does it run endurance cycles?

Yes. Repeated-action endurance is supported; see fatigue testing machines.
