Hot SaleModel No.: WH-CR-Lab
The Combi Boiler Test Rig (Model WH-CR-Lab) is a laboratory type-testing station for gas-fired combi and wall-hung boilers. Where the production wall-hung boiler test bench is configured for
| Model | WH-CR-Lab |
|---|---|
| Tests | Action / Tightness |
| Channels | Multi-channel |
| Delivery | 25–40 Days |
| Warranty | 1 Year + Lifetime Support |
| Origin | Zhongshan, Guangdong, China |
| MOQ | 1 Set (OEM available) |
The Combi Boiler Test Rig (Model WH-CR-Lab) is a laboratory type-testing station for gas-fired combi and wall-hung boilers. Where the production wall-hung boiler bench is configured for fast final QC, the WH-CR-Lab is built for R&D and certification: multi-channel action and tightness testing, detailed combustion and safety measurements, and precise data capture that engineers use to validate a new boiler design and compile certification files.
It is the station behind searches for a combi boiler test rig or combi boiler testing equipment for laboratory and notified-body work, and it is paired with the thermal efficiency test system for efficiency determination.
The rig is configured for type testing to EN 15502 and EN 297, supported by the EN 15502 boiler standard guide and wall-hung boiler certification testing; electrical/gas safety follows IEC 60335-2-102. The complete item list appears in key test items for wall-hung boilers. Wanhe provides the measurement and documentation support summarized on certifications.
| Aspect | Test rig (this page) | Production bench |
|---|---|---|
| Primary purpose | Certification & R&D type testing | Final QC of every unit |
| Data capture | Continuous logging across the full range | Fixed pass/fail sequence |
| Output | Traceable type-test report | Per-serial-number report |
| Reference | EN 297 / EN 15502 | EN 15502 / GB 25034 |
The rig combines a gas meter, water flow meters, temperature and pressure sensors and a flue-gas analyser with a data-acquisition system, so efficiency and performance are calculated from synchronised measurements rather than manual readings. For efficiency-focused work it is used together with the thermal efficiency test system, which provides the heat-input/output and flue-gas analysis modules.
Test methods follow EN 297 and EN 15502 for gas-fired boilers and EN 625 for combi boiler hot-water performance, with GB 25034 available for the Chinese market. The standards and the available document set are listed on our certifications page, and a real laboratory installation is shown in the EU wall-hung boiler lab bench case study.
| What you need | How the rig delivers |
|---|---|
| EN 297 / EN 15502 type-test data | Pre-configured test items and continuous logging |
| Defensible certification records | Synchronised, traceable, exportable measurements |
| Coverage of heating and DHW | One station for both functions of a combi boiler |
| Custom laboratory layout | Sensors, gas type (LPG/NG) and ranges configured to your models |
A laboratory installation is documented in the EU wall-hung boiler lab bench case; for production QC rather than type testing, see the wall-hung boiler test bench.
Wanhe Testing (Zhongshan, Guangdong) has designed and built gas-appliance test benches for appliance makers and certification laboratories for more than 15 years. Each bench is manufactured and calibrated in-house, ships with a 1-year warranty plus lifetime technical support, and can be OEM/ODM customised for your gas type, station count and data format. You can review our compliance credentials on the certifications & compliance page, compare the factory-direct model on Factory Direct, and read a buyer-focused checklist in how to choose a test-equipment manufacturer.
Send us your appliance models, target markets and the standards you must meet (EN, IEC, GB or ANSI). Wanhe engineers will propose a station layout, confirm the measurement ranges and provide a quotation with lead time and MOQ. Use the contact form, or review typical budget ranges in our gas test equipment price guide.
The WH-CR-Lab is a laboratory type-testing rig for R&D and certification. Production final QC uses the WH-BG02 wall-hung boiler bench.
Yes, and it is commonly paired with the thermal efficiency test system and flue-gas analysis for the efficiency calculation.
Yes. Frames, sensors and gas/water circuits are custom-engineered; see custom lead time.
Who Uses This Test Bench
Endurance certification of push buttons, micro switches and relays.
Cycle durability of gas and water valves under operating conditions.
Aging verification of controls and actuators in final products.
Answers to common questions from global customers about customization, delivery, certification and after-sales support.
We provide a 1-year whole-machine warranty. During the warranty period, non-human damage is repaired free of charge. The compressor of environmental chambers and other long-life parts follow the manufacturer warranty terms.
Yes. We can manufacture strictly according to your drawings, technical documents or samples. Our engineers will verify key parameters and tolerances with you before production to make sure the result matches your design intent.
For any issue, contact our after-sales team via email or WhatsApp with photos or a short video. We provide 24-hour online remote support to diagnose and guide repairs. Spare parts are shipped express if replacement is needed.
We respect customer confidentiality, but we are happy to arrange video calls with existing customers in similar industries or share published case studies (see the Project Cases section) as references.
We support EXW, FOB, CIF and other common Incoterms. For most overseas orders we recommend FOB Shenzhen or Guangzhou; for turnkey projects we can also provide DDP service including customs clearance and inland delivery.
