Professional

Gas Appliance Test Bench

Comprehensive testing for gas stoves, wall-hung boilers and water heaters on combustion performance, safety protection and thermal efficiency.

15+ Test Items LPG / NG Dual Gas 0.5 Class Accuracy PLC + Touch Screen IEC / EN / GB

Factory Direct Custom quotation · MOQ 1 set

Get a Quote Download Catalog

Technical Specifications

Key Parameters

Parameter	Specification
Test Items	Ignition, flame stability, thermal efficiency, gas tightness, flame failure protection, CO emission, surface temperature
Gas Types	LPG / Natural Gas / Town Gas (custom gas source)
Measurement Accuracy	0.5 Class (pressure & flow)
Control System	Computer + PLC or Touch Screen + PLC
Data Recording	Automatic acquisition, traceability & report export
Stations	1–6 stations (independent control)
Power Supply	220V/50Hz or custom (110V/60Hz available)
Standards	IEC / EN / GB compliant test methods
After-sales	1-year warranty, video debugging & remote support

Applications

Batch production line QC of ignition, combustion stability and thermal efficiency for gas stoves and integrated stoves.

Performance and safety verification for wall-hung boilers and gas water heaters under different gas sources.

Standardized test platform for certification inspection with data traceability and report export.

Tell us your test items, gas type and production line layout. Our engineers in Zhongshan will tailor the bench to your exact requirements.

Huangpu, Zhongshan, Guangdong, China Custom Test Items IEC / EN / GB Standards Export Worldwide
